LaVoce MAF082.00 8” Midrange Ferrite Magnet Aluminum Basket Speaker 400 Watts
- 2 INCH COPPER VOICE COIL
- 98,5 dB/SPL SENSITIVITY
- 400 WATT PROGRAM POWER HANDLING
- FEM OPTIMIZED MOTOR AND SUSPENSIONS
- OPTIMIZED COOLING SYSTEM
- COPPER RING FOR EXTENDED FREQUENCY RESPONSE
- TRIPLE ROLL SURROUND
GENERAL SPECIFICATIONS
- Nominal diameter mm (in.) 200 (8)
- Nominal impedance Ω 8
- Minimum impedance Ω 7,5
- Program power (1) W 400
- AES Power rating (2) W 200
- Sensitivity (3) dB 98,5
- Frequency range Hz 90 ÷ 5000
- Voice coil diameter mm (in.) 51 (2)
- Chassis material Aluminium
- Magnet material Ferrite
- Magnet dimensions OD x ID x h mm(in.) 155 x 60 x 17,5 (6.1 x 2.36 x 0.69)
- Coil material Copper
- Former material Polyimide
- Cone material Water Resistant Treated Paper
- Surround material Polycotton
- Xmax (4) mm (in.) 2,6 (0.1)
- Xmech (5) mm (in.) 6,6 (0.26)
- Gap height mm (in.) 8 (0.31)
- Voice coil winding height mm (in.) 9,2 (0.36)
- Driver displacement volume l (ft3) 0,99 (0.035)
- Recommended enclosure l (ft3) 14,7 (0.52)
- Recommended tuning Hz 100
SMALL SIGNAL PARAMETERS
- DC resistance Re Ohm 5,8
- Resonance frequency Fs Hz 75
- Moving mass Mms g (oz) 20,6 (0.73)
- Compliance Cms mm/N 0,217
- Force factor BxL N/A 17,33
- Mechanical Q-factor Qms 6,47
- Electrical Q-factor Qes 0,19
- Total Q-factor Qts 0,18
- Equivalent air volume Vas l (ft3) 13,54 (0,48)
- Voice coil Inductance Le mH 0,54
- Diaphragm area Sd cm2 (in.2) 210 (32,6)
- Reference efficiency Eta 0 % 2,95
- Efficiency bandwidth product EBP Hz 395
SHIPPING INFORMATION
- Net weight kg (lb.) 4,1 (9)
- Multipack size (1) W x D x H mm(in.) 270 x 270 x 140 (10.6 x 10.6 x 5.5)
- Multipack weight kg (lb.) 4,7 (10.4)
UPC
- 848864061481
