Shure SLXD1-H55 Bodypack Digital Wireless Transmitter for SLX-D Mic Systems
Key Features
- For SLX-D Receivers
- Use with Lav/Headset Mic or Instrument
- TA4M Connector
- 1760 Auto-Scan Frequencies
- 1/10mW RF Output Power
- LCD Screen
- Compatible with 8-Hr Rechargeable SB903
- Docked Recharging with Battery Inside
The Shure SLXD1 is a bodypack digital wireless microphone transmitter compatible with SLX-D receivers. It delivers crystal-clear, 24-bit digital audio quality and reliable RF performance—well suited for use in small- to medium-sized venues and houses of worship, or with A/V installations in conference, educational, or corporate facilities.
The Shure SLXD1 is a bodypack digital wireless microphone transmitter compatible with SLX-D receivers. It delivers crystal-clear, 24-bit digital audio quality and reliable RF performance—well suited for use in small- to medium-sized venues and houses of worship, or with A/V installations in conference, educational, or corporate facilities.
The SLXD1 operates in a 44 MHz UHF tuning range with 1760 frequencies available and features a selectable 1/10mW RF power output and a transmission range up to 330'. It provides up to 8 hours of operation on two AA batteries or an SB903 rechargeable battery (available separately).
User Friendly, Compact, and Lightweight
- The SLXD1 features a TA4M input, allowing you to choose a lavalier or headset mic with a TA4F connector for hands-free presentations and performances, or a dedicated WA305 locking instrument cable for use with a guitar/bass (mic and cable available separately).
The unit quickly syncs with a wireless receiver via infrared at the touch of a button. - An easy-to-read LCD shows important information.
- 1/10mW selectable RF output power allows you to increase either the transmitter's range or the number of mics operating simultaneously.
- The discreet, ergonomic housing is constructed from tough, lightweight ABS plastic and features a fixed 1/4 wave antenna.
Convenient Power Management Options
- The SLXD1 operates for up to 8 hours on two AA batteries or an SB903 rechargeable battery (available separately).
- The SB903 lithium-ion rechargeable battery offers convenient power management with zero memory effect and precision metering in hours and minutes on the transmitter's LCD screen.
- The SBC203 dual-battery recharging station (available separately) charges two SB903 batteries at once—it fits the external contacts on the transmitter so you don't have to remove the batteries to recharge.
Key Specs
- Wireless Technology : Digital UHF
- Max Operating Range : 328' / 100 m
- Included Transmitters : 1x Bodypack
- Microphone Type : No Microphone Included
- Included Charging Case : No
System
- Wireless Technology: Digital UH
- RF Frequency Band : H55: 514 to 558 MHz
- Max Operating Range : 328' / 100 m
- Max Transmitters per Band : 32
- Latency : 3.2 ms
- Encryption : No
- Built-In Recorder : No
- Timecode Support : No
- Mobile App Compatible : No
Transmitters
- Included Transmitters : 1x Bodypack
- RF Output Power : 10 / 1 mW (Selectable)
- Antenna : Fixed 1/4 Wave External
- Input Level : Microphone / Instrument
- Audio I/O : 1x TA4M/Mini-XLR 4-Pin Male Input
- Bias/Plug-In & Phantom Power : Has Bias/Plug-In Power: Voltage is Unspecified No Phantom Support
- USB I/O : No
- Muting : No
- Gain Range : 0 to +21 dB
- Auto-Level/Gain : No
- Frequency Response : 20 Hz to 20 kHz (Dependent on Mic)
- Sync Method : IR
- Display : OLED
Microphone
- Microphone Type : No Microphone Included
Power
- Transmitter Battery Type : 2x AA (Included) or
- 1x Shure SB903 (Not Included) : Transmitter Battery Life
- 8 Hours (Lithium Shure SB903) : 8 Hours (Alkaline)
- Battery Charging Time : 1.25 to 5.5 Hours
- Included Charging Case : No
- AC/DC Power Adapter :No
Physical
- Environmental Resistance : No
- Housing : Plastic, ABS
- Dimensions : 2.7 x 3.9 x 1" / 68 x 98 x 25.5 mm
- Weight : 3.1 oz / 89 g
Packaging Info
- Package Weight : 0.75 lb
- Box Dimensions (LxWxH) : 11.2 x 5.3 x 3.2"
UPC
- 042406560122
