JVC KW-M785BW Digital Media Receiver featuring 6.8-inch Capacitive Touch Control Monitor (6.8" WVGA) / Wireless Apple CarPlay / Wireless Android Auto / USB Mirroring for Android Phones / iDatalink Maestro Ready / HDMI Input / Bluetooth® / 13-Band EQ / Short Chassis
KW-M785BW
Monitor
-
Screen Size: 6.8"W VGA Screen
-
Touch Panel: Capacitive
-
Gesture Touch Control: Yes
-
Customizable GUI: Yes
-
Key Illumination Color: Variable
-
Dimmer: Yes
-
Multilingual Display: Yes
-
Wallpaper Capture: Yes
Media Playback
-
MP3 Compatible with Tag: USB
- WMA Compatible with Tag: USB
-
WAV Compatible with Tag: USB
-
AAC Compatible with Tag: USB
-
FLAC Compatible with Tag: USB
-
H.264 Compatible: USB
-
WMV Compatible: USB
-
MPEG 1/2 Compatible: USB
-
MPEG 4 Compatible: USB
-
MKV Compatible: USB
Bluetooth Control
-
Built-in Bluetooth: Yes (Wired-Mic included)
-
Hands Free Call: Yes (HFP1.8 Wideband Speech)
-
2 Phones Full-Time Connection: Yes
-
Audio Streaming & Control (A2DP, AVRCP): Yes
-
Supported Audio Formats: AAC / SBC
-
5 BT-Audio Connection: Yes
-
Voice Dialing (voice recognition compatible mobile phone required): Yes
-
Phone Book Access Profile (PBAP): Yes
-
Alphabetical Search for Phone Book: Yes
-
Auto Pairing for iPhone/Android: Yes
Wi-Fi Control
-
Built-in Wi-Fi: Yes
Android Control
-
Android Auto: Yes (via Wi-Fi or USB)
-
Mirroring for Android: Yes (via USB) *Need mirroring App
-
Android Music Playback: Yes (via Bluetooth(R))
iPod/iPhone Control
-
CarPlay[3]: Yes (via Wi-Fi or USB)
-
iPhone Music Playback: Yes (via USB(CarPlay) or Bluetooth(AVRCP))
USB
-
USB Port: x 1 (High speed)
-
Position: Rear
-
USB Power Supply: Yes (1.5A High Current Charging)
-
Drive Change Mode for Mass Storage Class (selectable from internal/external memory): Yes
Radio Tuner
-
-
SiriusXM Ready: Yes
-
Radio Broadcast Data System (RBDS): Yes
-
Preset Stations: 20(FM:15ch, AM:5ch)
-
-
FM
-
Frequency Range :87.9 - 107.9MHz
AM
-
Frequency Range: 530-1,700kHz
Audio
-
Maximum Power Output (Front & Rear): 50Wx4
-
Full Bandwidth Power (Front & Rear): 22W x 4 (Full Bandwidth Power, at less than 1% THD)
-
EQ: Yes (13-Band Graphic EQ)
-
Preset EQ: Yes (8Preset + 4user)
-
Bass Boost: Yes
-
High-Pass Filter/Low-Pass Filter: Yes/Yes
-
3-Way X'over: Yes
-
Digital Track Expander: Yes
-
Space Enhancement: Yes
-
Sound Response: Yes
-
Sound Lift: Yes
-
Volume Link EQ: Yes
-
Time Alignment: Yes
Inputs and Outputs
-
AV Input: mini jack (AV-IN or Camera-IN switchable) x 1
-
Video Out: RCA x 1
-
HDMI Terminal: Yes
-
Rear view camera Input: Yes
-
Front view camera Input: Yes
-
Line Output Terminals: 3 Pairs (Front + Rear + Subwoofer)
-
Pre-output Level/Impedance: 4.0V / 10k ohms
General
-
iDatalink Maestro Ready: Yes
-
Back Up Memory: Yes
-
Viewing Angle Adjustment: Yes (0 - 20 degree, default : 0 degree)
-
Short Chassis: Yes (2-15/16inch, 75mm)
-
Wireless Remote Control: Ready (RM-RK258 required)
-
Steering Remote Control Ready: Yes
Dimensions (W x H x D)
-
Installation Size: 7-1/16" x 3-15/16" x 2-15/16" (180 x 100 x 75 mm)
-
Weight: 2.7 lbs. (1.2kg) Including Sleeve and Trim plate
-
Unit weight in individual package: 4.2 lbs. (1.9kg)
-
[1]Available functions depend on mobile phone.
[2]To use Android Auto on your car display, youll need an Android phone running Android 6 or higher, an active data plan, and the Android Auto app. The service may not be available in certain countries.
[3]Supported on iPhone XR, iPhone XS, iPhone XS Max, iPhone 11, iPhone 11 Pro, iPhone 11 Pro Max, iPhone 12, iPhone 12 mini, iPhone 12 Pro, iPhone 12 Pro Max, iPhone 13, iPhone 13 mini, iPhone 13 Pro, iPhone 13 Pro Max, iPhone SE (2nd generation), and Apple Watch Series 5 or later. The service may not be available in certain countries.
[4]Multilingual (English / Spanish / French)
