Eminence OMEGA PRO-18A 18" Professional Pro Audio Replacement Woofer 1600W 8-Ohm

(No reviews yet) Write a Review
SKU:
Eminence OMEGA PRO-18A T.C.
UPC:
876358000425
Condition:
New
Availability:
Free Shipping
Type:
Subwoofer
Size:
18 Inch
RMS Power:
800 Watts
Ohms:
8 Ohms
Magnet:
Ferrite
Qty.:
1 Speaker
Order before 3PM (EST) Mon-Fri for Same Day Shipping
$264.99

Product Description

Eminence OMEGA PRO-18A 18" Professional Pro Audio Replacement Woofer 1600W 8-Ohm

Recommended for professional audio as a woofer in vented enclosures. Also ideal for horn loading and scoops.

Applications:

  • Subwoofer | Woofer | Pro Audio

  • Box Type: Vented | Scoop Loading | Horn Loading

SPECIFICATION
Nominal Basket Diameter
  • 18", 457 mm
Nominal Impedance
  • 8 Ω
Power Rating
Program Power
  • 1600 W
Watts
  • 800 W
Resonance
  • 25 Hz
Usable Frequency Range
  • 40 Hz - 0.8 kHz
Sensitivity*
  • 97 dB
Magnet Weight
  • 109 oz.
Gap Height
  • 0.375", 9.5 mm
Voice Coil Diameter
  • 4", 102 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)
  • 25 Hz
DC Resistance (Re)
  • 5.2 Ω
Coil Inductance (Le)
  • 1.67m H
Mechanical Q (Qms)
  • 8.18
Electromagnetic Q (Qes)
  • 0.32
Total Q (Qts)
  • 0.31
Compliance Equivalent Volume (Vas)
  • 548.7 liters / 19.38 cu.ft.
Peak Diaphragm Displacement Volume (Vd)
  • 556 cc
Mechanical Compliance of Suspension (Cms)
  • 0.29 mm/N
BL Product (BL)
  • 18.8 T-M
Diaphragm Mass Inc. Airload (MMs)
  • 137 grams
Efficiency Bandwidth Product (EBP)
  • 79
Maximum Linear Excursion (Xmax)
  • 4.8 mm
Surface Area of Cone (Sd)
  • 1159 cm2
Maximum Mechanical Limit (Xlim)
  • 16 mm
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed
  • N/a
Vented
  • 96-198 liters / 3.4-7 cu.ft.
Driver Volume Displaced
  • 0.234 cu.ft. / 6.62 liters
Overall Diameter
  • 18", 457.2 mm
Baffle Hole Diameter
  • 16.56", 420.6 mm
Front Sealing Gasket
  • Yes
Rear Sealing Gasket
  • Yes
Mounting Holes Diameter
  • 0.28", 7.1mm
Mounting Holes B.C.D.
  • 17.25", 438.2mm
Depth
  • 8.15", 207 mm
Net Weight
  • 25.2 lbs, 11.43 kg
Shipping Weight
  • 28.9 lbs, 13.11 kgs
MATERIALS OF CONSTRUCTION
Coil Construction
  • Copper voice coil
Coil Former
  • Polyimide former
Magnet Composition
  • Ferrite magnet
Core Details
  • Vented and extended core
Basket Materials
  • Die-cast aluminum basket
Cone Composition
  • Paper cone
Cone Edge Composition
  • Cloth cone edge
Dust Cap Composition
  • Solid composition paper dust cap
