Chauvet Obey 40 16-Channel DMX-512 Universal DJ LED Light Controller
- The Obey 40 is the next step up from the Obey 10, allowing for control of up to 12 fixtures at 16 channels each. With a slightly larger size comes a larger capacity: the Obey 40 has 30 banks on 8 scenes, or up to 240 scenes. The Obey 40 offers the flexibility of its little brother but also adds fog and strobe control and MIDI compatibility.
Highlights
-
Universal DMX controller capable of handling all the complexities of today's lighting fixtures
-
Easily control up to 12 intelligent lights with up to 16 channels each
-
Includes 192 channels of DMX control and 30 banks of 8 scenes for a maximum of 240 scenes
-
Enhance light shows with 6 sets of chase effects containing 240 scenes
-
Increase effects with fog and strobe control, beat activation, tap-sync and auto run
-
Capability to grab any fixture on the fly and sequentially link chases
-
Increase flexibility with MIDI compatibility and DMX polarity selector
-
Conveniently mounts using the 3-space (3U) mounting rack
Specifications
-
DMX Channels: 192
-
DMX Connectors: 3-pin XLR
-
Rackmount: 3U
-
Input Voltage: 9 VDC, 500 mA (external power supply: 100 to 240 VAC, 50/60 Hz)
-
Weight: 5.7 lb (2.6 kg)
-
Size: 19 x 3.5 x 6.7 in (483 x 89 x 171 mm)
-
Approvals: CE
What's Included
-
External power supply
-
Quick Reference Guide
-
Warranty card
