B&C 10CXN64 10" Professional Neodymium Titanium Coaxial Speaker
-
Continuing our never-ending quest for higher output, we now offer our popular single neodymium magnet coaxials with larger voice coils for increased power handling.
-
A significant increase in magnet mass also improves sensitivity and cone control, while integrating our latest compression driver technologies improves sound quality and durability in the HF as well.
-
For high output applications where fidelity at maximum SPL is the primary concern, consider the 10CXN64 with 2.5” LF & HF voice coils.
-
Power handling has increased to 500W, while also improving nearly every other parameter (including Xvar) relative to our established 10" coax models.
-
Features 500 W continuous program power capacity 70° nominal coverage 70 - 18000 Hz response 97 dB sensitivity Single Neodymium magnet assembly Aluminium demodulating ring allows a very low distortion figure
Features
-
500 W continuous program power capacity
-
70° nominal coverage
-
70 - 18000 Hz response
-
97 dB sensitivity
-
Single Neodymium magnet assembly
-
Aluminium demodulating ring allows a very low distortion figure
Specifications
- Nominal Diameter 250 mm (10.0 in)
- Nominal Impedance 8 Ω
- Minimum Impedance LF 6.7 Ω
- Minimum Impedance HF 7.0 Ω
- Frequency Range 70 - 18000 Hz
- Dispersion Angle 70 °
- Woofer Cone Treatment WP Waterproof Front Side
- Magnet Material Neodymium Ring
Specifications LF unit
- LF Sensitivity 97.0 dB
- LF Nominal Power Handling 250 W
- LF Continuous Power Handling 500 W
- LF Voice Coil Diameter 64 mm (2.5 in)
- LF Winding Material Copper
- LF Flux Density 1.1 T
- Former Material Kapton
- Winding Depth 15.0 mm (0.59 in)
- Magnetic Gap Depth 9.0 mm (0.35 in)
Specifications HF unit
- HF Sensitivity 103.0 dB
- HF Nominal Power Handling 80 W
- HF Continuous Power Handling 160 W
- HF Voice Coil Diameter 65 mm (2.5 in)
- HF Winding Material CCAW
- HF Flux Density 1.75 T
- Diaphragm Material Titanium
- Recommended Crossover 1.2 kHz
- Inductance 0.15 mH
Parameters
- Resonance Frequency 68 Hz
- Re 5.6 Ω
- Qes 0.33
- Qms 5.6
- Qts 0.31
- Vas 23.0 dm3 (0.81 ft3)
- Sd 320.0 cm2 (49.6 in2)
- ηâ‚€ 2.2 %
- Xmax± 5.5 mm
- Xvar± 5.0 mm
- Mms 33.5 g
- Bl 15.8 Txm
- Le 1.1 mH
- EBP 206 Hz
Mounting and Shipping Info
- Overall Diameter 261 mm (10.28 in)
- Bolt Circle Diameter 245 mm (9.65 in)
- Baffle Cutout Diameter 233 mm (9.17 in)
- Depth 142 mm (5.59 in)
- Flange and Gasket Thickness 13 mm (0.51 in)
- Net Weight 3.2 kg (7.05 lb)
- Shipping Units 1
- Shipping Weight 4.1 kg (9.04 lb)
- Shipping Box 360x360x200 mm (14.17x14.17x7.87 in)
