2x Eminence DELTALITE II 2512 12" Neodymium Speaker - Series II 500 Watts 8-Ohm

(No reviews yet) Write a Review
SKU:
2x Eminence DELTALITE II 2512 T.C.
UPC:
876358000593
Condition:
New
Availability:
Free Shipping
Order before 3PM (EST) Mon-Fri for Same Day Shipping
$379.98

Product Description

Eminence DELTALITE II 2512 12" Neodymium Speaker - Series II 500 Watts 8-Ohm

Suited for pro audio as a mid/hi or full-range and monitor. Also recommended for bass guitar. Works well in sealed or vented enclosures.

Applications

  • Woofer | Midbass | Pro Audio | Home Stereo | Home Theater | Bass Guitar

  • Box Type: Sealed | Vented | Horn Loading

SPECIFICATION
Nominal Basket Diameter
  • 12", 305 mm
Nominal Impedance*
  • 8 Ω
Power Rating*
Program Power
  • 500 W
Watts
  • 250 W
Resonance
  • 44 Hz
Usable Frequency Range
  • 58 Hz - 4.3 kHz
Sensitivity*
  • 99.9 dB
Magnet Weight
  • 7 oz.
Gap Height
  • 0.275", 7 mm
Voice Coil Diameter
  • 2.5", 64 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)
  • 44 Hz
DC Resistance (Re)
  • 5.17 Ω
Coil Inductance (Le)
  • 0.43m H
Mechanical Q (Qms)
  • 4.17
Electromagnetic Q (Qes)
  • 0.45
Total Q (Qts)
  • 0.41
Compliance Equivalent Volume (Vas)
  • 134.88 liters / 4.76 cu.ft.
Peak Diaphragm Displacement Volume (Vd)
  • 255 cc
Mechanical Compliance of Suspension (Cms)
  • 0.36 mm/N
BL Product (BL)
  • 10.69 T-M
Diaphragm Mass Inc. Airload (MMs)
  • 37 grams
Efficiency Bandwidth Product (EBP)
  • 96
Maximum Linear Excursion (Xmax)
  • 4.9 mm
Surface Area of Cone (Sd)
  • 519.5 cm2
Maximum Mechanical Limit (Xlim)
  • 8.5 mm
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed
  • 25.49-42.48 liters / 0.9-1.5 cu.ft.
Vented
  • 32.56-127.43 liters / 1.15-4.5 cu.ft.
Driver Volume Displaced
  • 0.05 cu.ft. / 1.42 liters
Overall Diameter
  • 12.38", 314.5 mm
Baffle Hole Diameter
  • 11.06", 280.9 mm
Front Sealing Gasket
  • Yes
Rear Sealing Gasket
  • Yes
Mounting Holes Diameter
  • 0.28", 7.1mm
Mounting Holes B.C.D.
  • 11.62", 295.2mm
Depth
  • 6.06", 153.9 mm
Net Weight
  • 5.1 lbs, 2.31 kg
Shipping Weight
  • 6.8 lbs, 3.08 kgs
MATERIALS OF CONSTRUCTION
Coil Construction
  • Aluminum voice coil
Coil Former
  • Polyimide former
Magnet Composition
  • Neodymium magnet
Core Details
  • Vented core
Basket Materials
  • Die-cast aluminum basket/ heatsink
Cone Composition
  • Paper cone
Cone Edge Composition
  • Cloth cone edge
Dust Cap Composition
  • Solid composition paper dust cap
