Shure UA874 US Active Directional UHF and VHF Antenna, Wireless Signal Reception

Shure UA874 US Active Directional UHF and VHF Antenna, Wireless Signal Reception

Shure

Write a Review
SKU:
Shure UA874US T.C.
Condition:
New
UPC:
042406256308
Avaliability:
Free Shipping
Order before 2PM (EST) Mon-Fri for Same Day Shipping
Store Pick Up Available We Price Match! Call Us On 718-272-7228
Now: $404.00
Adding to cart… The item has been added
Make an Offer
Award-Winning Service
Free Shipping Orders $49+
30 Days
Easy Returns
Guaranteed
Lowest Price
In-House
Experts

Financing Available

Shure UA874US Active Directional UHF and VHF Antenna Delivers Improved Wireless Signal Reception With Integrated Amplification.

The Shure UA874 Active Directional Antenna uses a log periodic dipole array to offer enhanced reception when directed toward the desired coverage area. An integrated amplifier and four gain settings compensate for varying degrees of coaxial cable signal loss. The UA874 can be mounted on a microphone stand, suspended from the ceiling or mounted to a wall using the integrated swivel adapter bracket.

  • Compatible with all Shure wireless receivers and antenna distribution systems that provide 12 V DC bias
  • Four-position gain selector switch
  • Low-noise signal amplifier that compensates for transmission loss in coaxial cable
  • Integrated threaded adapter that mounts easily to microphones stands

Specifications

Connector Type
  • BNC (female)
Impedance
  • 50 ohms
Reception Pattern
  • 70° (3 dB beam width)
Overload Intercept Point
  • >30 dBm
Antenna Gain
  • 7.5 dBi (on axis)
Signal Gain
  • Switchable
    Active: +12 dB, +6 dB (±1 dB)
    Passive: 0 dB, -6 dB (±1 dB)
RF Overload LED Threshold
  • -5 dBm (RF overload LED does not operate for passive gain settings)
Power Requirements
  • 10 - 15 V DC bias from coaxial connection (75 mA)
Operating Temperature Range
  • 0 to 145°F (-18 to 63°C)
Storage Temperature Range
  • -20 to 165°F (-29 to 74°C)
Dimensions
  • 14.1 x 12.4 x 1.4" (359 x 316 x 36 mm)
Weight
  • 11.2 oz (317 g)
Packaging Info
Package Weight
  • 2.305 lb
Box Dimensions (LxWxH)
  • 18.7 x 15.5 x 3.7"
