Shure SLXD14D G58 Dual Digital Wireless System w/ 2x SLXD1 Bodypack Transmitters

Shure SLXD14D G58 Dual Digital Wireless System w/ 2x SLXD1 Bodypack Transmitters

Shure

Write a Review
SKU:
Shure SLXD14D-G58 T.C.
Condition:
New
UPC:
042406597852
Avaliability:
Free Shipping
Order before 2PM (EST) Mon-Fri for Same Day Shipping
Store Pick Up Available We Price Match! Call Us On 718-272-7228
Now: $1,279.00
Adding to cart… The item has been added
Make an Offer
Award-Winning Service
Free Shipping Orders $49+
30 Days
Easy Returns
Guaranteed
Lowest Price
In-House
Experts

Financing Available

Shure SLXD14D Dual Digital Wireless System with Two SLXD1 Bodypack Transmitters and Two WA305 Instrument Cables for Guitar / Bass

Featuring two SLXD1 transmitters, the SLXD4D provides transparent digital audio and rock-solid RF stability for lecture halls and live performances.

  • The SLXD14D Dual Wireless System delivers transparent, 24-bit digital audio and rock-solid RF performance for a wide range of applications, from day-long presentations to nighttime performances.

  • Operate up to 32 compatible systems per 44 MHz band, with easy setup and optional rechargeability accessories for wireless excellence, wherever required.

  • Ships with SLXD4D dual-channel receiver and 2 SLXD1 bodypack transmitters with antenna and rackmount accessories and 4 AA batteries.

Specifications

System

Wireless Technology
  • Digital UHF
Number of RF Channel Frequencies
  • 1760
Included Transmitters
  • 2x Bodypack
Diversity
  • True Digital Diversity
RF Frequency Band
  • G58: 470 to 514 MHz
RF Bandwidth
  • 44 MHz
Frequency Step Size
  • 25 kHz
RF Channel Scanning
  • Auto-Scan
Max Operating Range
  • 328' / 100 m
Max Transmitters per Band
  • 32
Bluetooth
  • Not Specified by Manufacturer
Sample Rate/Resolution
  • 24-Bit
Latency
  • 3.2 ms
Dynamic Range
  • 120 dBA (Typical)
Receiver
Receiver Type
  • Tabletop / Rackmount
Mounting Options
  • Rackmount (with Included Hardware)
Rackmount Size
  • 1 RU (Full Rack)
Antenna
  • 2x 1/4 Wave External, BNC (Rear-Mount)
Number of Audio Channels
  • 2
Audio I/O
  • 2x XLR 3-Pin Male Balanced Mic/Line Output
    2x 1/4" TRS Female Balanced Output
Gain Range
  • 0 to +21 dB (3 dB Steps)
Pad
  • 30 dB
Audio Output Level
  • -18 to +42 dB (Balanced, Unbalanced)
Frequency Response
  • 20 Hz to 20 kHz +1/-2 dB (Dependent on Mic)
Impedance
  • 1/4" Outputs:

    • 1.3 Kilohms (Balanced)

    • 670 Ohms (Unbalanced)

    XLR Outputs:

    • 400 Ohms (Balanced)

    • 150 Ohms (Balanced)
Approximate RF Sensitivity
  • -97 dBm
Adjacent Channel Isolation
  • >70 dB
Spurious
  • Rejection: >75 dB
Power Requirements
  • AC/DC Power Adapter
AC/DC Power Adapter
  • 15 VDC at 600 mA, Center-Positive (Included)
AC Input Power
  • 100 to 240 VAC, 50 / 60 Hz
Display & Indicators
  • LCD (AF Level, Channel, Frequency, Group, RF Level, Transmitter Battery Status)
Housing
  • Steel
Operating Temperature
  • 0 to 122°F / -17 to 50°C
Storage Temperature
  • -20 to 165°F / -28 to 73°C
Dimensions
  • 15.5 x 1.7 x 6" / 393 x 42 x 152 mm
Weight
  • 3.2 lb / 1451 g (without Antenna)
Transmitter
Transmitter Type
  • Bodypack
RF Output Power
  • 1 / 10 mW
Audio I/O
  • 1x TA4/Mini-XLR 4-Pin Male Unbalanced Input (Locking)
Included Cable Connector
  • No
Pad
  • No
Muting
  • No
Gain Range
  • 0 +21 dB
Signal Processing
  • No
Sync Method
  • IR
Antenna
  • 1/4 Wave External, Fixed
Power Requirements
  • Battery
Battery Type
  • 2x AA (Included)
    1x Shure SB903 (Not Included)
Battery Charging Time
  • 1.25 to 5.5 Hours
Approx. Battery Life
  • 8 Hours (Lithium Shure SB903)
    8 Hours (Alkaline)
USB/Lightning I/O
  • No
Display & Indicators
  • LCD (Battery Status, Channel, Group)
Housing
  • ABS, Plastic
Operating Temperature
  • 0 to 122°F / -17 to 50°C
Storage Temperature
  • -20 to 165°F / -28 to 73°C
Dimensions
  • 2.7 x 3.9 x 1" / 68 x 98 x 25.5 mm
Weight
  • 3.1 oz / 89 g
Packaging Info
Package Weight
  • 8.405 lb
Box Dimensions (LxWxH)
  • 17.8 x 13.8 x 4.6"
