The RCF CD850 2.0 is a high performance 3.0-inch diaphragm compression driver with a 2 inch exit throat featuring several state of the art technologies.
The diaphragm are precision formed from pure titanium. The suspension is based on a vented and damped design in order to provide low distorsion. Voice coil assembly is designed using high temperature kapton former.
Features
- 3-inch Diaphragm, 2-inch Exit Throat / Pure Titanium Compression Driver
- 220W continuous program power handling
- Frequency range: 500Hz - 20kHz
- 3-slot optimized geometry phase plug
- Ceramic Magnet Assembly
- Copper inductance ring for extended response
- Vented, damped, low distortion suspension system
Applications
- High power professional applicationms
- 2 way and multiple way systems
- Long throw and large format line arrays
- Very good linearity in combination with RCF H6040 horn
Specifications
- Exit Throat Diameter: 50 / 2.0 mm/inch
- Rated Impedance: 8
- Power handling capacity continuous program1: 220 W AES
- Power handling capacity AES2: 110 W AES
- Sensitivity: 109 dB
- Frequency Range: 500 Hz ÷ 20000 Hz
- Diaphragm Material: Pure titanium
- Suspension Material: Polyester
- Suspension Design: Flat
- Minimum Impedance: (at 3.5kHz) 8.5
- Voice Coil Diameter: 74.4 / 3.0 mm/inch
- Voice Coil Material: Edgewound aluminium
- Voice Coil Former Design: Straight kapton
- Number of layers: 1 - outside
- BL Factor: 12.3 T · m
- Flux Density: 1.9 T
- Phase Plug Design: 3 slots
- Phase Plug Material: Composite
- Magnetics: Ceramic
- Voice Coil Demodulation: Copper ring
Mounting information
- Overall diameter: 180 / 7.1 mm/inch
- Overall height: 88 / 3.5 mm/inch
- Mounting 4 × 5 mm holes at 90°: 101.6 / 4.0 mm/inch
- Net weight: 5.5 / 12.1 kg/lbs
Shipping information
- Shipping weight: 6.0 / 13.2 kg/lbs
