1x 12MR1000 PRO - 12" Midrange High Output Loudspeaker - 1000 Watts

FEATURES:

The 12MR1000 PRO is a high power, and high output 12” midrange from our PRO Series primarily designed to perform in small sealed, horn loaded and vented enclosures, making it the perfect choice for a variety of installations, including professional sound reinforcement, live sound, home audio speakers with high outputs, as well as high SPL car audio.
  • Excellent performance in 3-way systems, with high detailed percussion instruments tones at a high sensitivity of 99 dB
  • Premium paper cone and cloth surround for high clarity, smooth response, and linear excursion at high 1000 Watts RMS program power.
  • 3” Inside/outside wound CCAW voice coil leads on fiberglass former lend solid power handling capability
  • Under spider and rear periphery venting allows cool running voice coil on long-lasting playing sessions.
  • Low Qts means high damping and excellent performance in smaller boxes.

This professional midrange loudspeaker delivers smooth, clear vocals that will impress any listener! Its high efficiency makes it easy to power, all thanks to a specially light weight cone designed to deliver smooth vocals and well define midbass tones.


Cast aluminum frame adds structural integrity, while a paper/glass fiber cone attached to a large 3″ voice coil keeps everything under control at high level outputs, making an easy transition to a high frequency driver.



GENERAL SPECIFICATIONS

Nominal Diameter12″ (305 mm)
Nominal impedance8 Ohm
Nominal Power Handling*500 Watts
Continuous Program Power (RMS)**1000 Watts
Max Peak Power***2000 Watts
Sensitivity 2.83V at 1m99 dB
Recommended Hi Pass Crossover For Full Power Handling125 Hz 12db Per Octave Crossover
Frequency Response70 – 6,500 Hz
Voice Coil Diameter3″ (75 mm)
Voice Coil WireCCAW
Voice Coil Winding Depth11.0 mm
Former MaterialGlass Fiber
Magnetic Gap Depth10 mm
Frame MaterialDie cast Aluminum
12MR1000 PRO Frequency Response

THIELE-SMALL PARAMETERS

Equivalent VolumeVas92.3 l
Excursion (mathematical)***Xmax3.00 mm
Free Air ResonanceFs49.4 Hz
Mechanical FactorQms12.05
Electrical FactorQes0.40
Total FactorQts0.39
Cone AreaSd577 cm²
Mechanical MassMms52.31 g
Bl FactorBl15.89 Tm
Dc ResistanceRe6.2 Ohm
InductanceLe0.60 mH at 1 kHz
Mechanical Mass Without AirMmd44.5 g
Mechanical ComplianceCms0.199 mm/N


12MR1000 PRO Impedance

EXTRA INFO

Overall Diameter12.40” (315 mm)
Front Mount Baffle Cutout11.16” (283.5 mm)
Mounting Depth5.12” (130 mm)
Overall Depth5.61” (142.5 mm)
Net Weight16.30 Lbs (7.40 kg)
Shipping Weight17.80 Lbs (8.06 kg)
Carton Dimensions W x L x H13.38”x 13.38” x 7.09” (340 x 340 x 180 mm)
