Pro S Replacement stylus - Stylus PRO S
No matter what the application, the Pro S provides remarkable versatility for virtually any setting and is a consistent performer and a fine all-arounder!
Specifications
-
Channel balance at 1 kHz: 2 dB
-
Output voltage at 1 kHz, 5cm/sec: 5 mV
-
Channel seperation at 1 kHz: 20 dB
-
Channel seperation at 15 kHz: 15 dB
-
Frequency response 20 Hz - 20 kHz: +/-2 dB
-
Tracking ability at 315Hz at recommended tracking force: 70 μm
-
Compliance, dynamic, lateral: 7 μm/m N
-
Stylus type: Spherical
-
Stylus tip radius: R 18 μm
-
Tracking force range: 3.0-5.0 g (30-50 mN)
-
Tracking force, recommended: 4.0 g (40 mN)
-
Tracking angle: 20°
-
Internal impedance, DC resistance: 750 Ohm
-
Cartridge weight: 18.5 g / 5.0 g
-
Recommended load resistance: 47 kOhm
-
Internal inductance: 450 mH
-
Recommended load capacitance: 200-600 pF
