DS18 PRO-SDF10 10" LOUDSPEAKER HORN DIFFUSER BLACK
With DS18’s PRO-SDF10, you can unleash focused beams of audio energy towards the crowd at your next local car meet. Designed for competition; the PRO-SDF10 is engineered to project audio for miles without compromising on sound quality.
Precision engineering is at the forefront of the PRO-SDF10’s design. The 248mm Speaker Bolt guarantees a secure fit onto your 10” Mid-Range Loudspeaker even when you turn the bass up a notch. The 6mm thickness of the diffuser guarantees durability and extended longevity, ensuring that your investment in your audio doesn’t go to waste.
The PRO-SDF10 comes with 4-M4 Nut-Inserts, so installation is a breeze. No need to hunt for additional hardware; we've got you covered. Within no time, the PRO-SDF10 will be installed and you’ll finally be able to get LOUD with the competition.
Features
- Loudspeaker Horn Diffuser Horn
- 10"
- Bolt on Installation
- Mounting Hardware Included
- Black ABS
Specifications
| Nominal Speaker Diameter (Not included) | 10" / 254mm |
| Nominal Horn Size | 12" / 304mm |
| Throat Diameter | 6.4x6.4" / 163x163mm |
| Installation Type | Bolt-On |
| Sound Coverage | 90° |
| Body Material | ABS |
| Color | Black Matte |
| SKU | PRO-SDF10 |
Measurement
| Overall Diameter | 11.93" / 303mm |
| Overall Depth | 5.94" / 151mm |
| Mounting Depth | 5.67" / 144mm |
| Mounting Hole Diameter | 10.8x10.8" / 275x275mm |
| Bolt Pattern (Speaker) | 9.76" / 248mm |
UPC
- 663593067524
