D.A.S Audio Vantec-18A 8" Bass Reflex Powered Subwoofer 2000 Watts Active Sub.

(No reviews yet) Write a Review
SKU:
D.A.S Vantec-18A T.C.
UPC:
8436542214155
Condition:
New
Availability:
Free Shipping
Order before 3PM (EST) Mon-Fri for Same Day Shipping
$1,849.00
Make An Offer

Product Description

D.A.S Audio Vantec-18A 8" Bass Reflex Powered Subwoofer 2000 Watts

Features

  • Powered subwoofer system

  • High output 18LX loudspeaker

  • Polarity switch (0º180º)

  • Filtered output defeat switch

  • Variable 80-125 Hz lowpass filter

  • Gain control

  • Rigging points

Applications

  • Concerts and corporate A/V

  • Portable and live clubs

  • Concert halls, theaters and auditoriums

  • Houses of worship

Description

The VANTEC-18A is a powered subwoofer system designed to provide extended bass response for the Vantec-full range cabinets. A 2000 Wpeak advanced Class D amplifier drives a DAS 18LX-long excursion loudspeaker incorporates a 4″ voice coil for high power handling and output.

The VANTEC-18A subwoofer system offers two balanced inputs with stereo filtered output connections for Vantec-satellite systems. The variable crossover ranges from 80 Hz 125 Hz and can be defeated to offer stereo “loop thru” connections. A gain control and polarity reverse feature increase user control over the system. A standard 35 mm pole mount socket allows the VANTEC-18A to be used with satellite systems.

Specifications

Performance
Frequency Range (-10 dB)
  • Loud: 35 Hz – 125 Hz – Deep: 30 Hz – 125 Hz
Maximum Peak SPL at 1 m
  • 134 dB
Electronics and Connectors
Nominal Amplifier Power (continuous)
  • 1000 W
Nominal Amplifier Power (peak)
  • 2000 W
Input Type
  • Balanced
Input Impeadance
  • 20 kohms
Input Sensitivity
  • 3 V (+12 dBu)
Audio Signal Input Connector
  • 2 x Female XLR
Audio Signal Loop Thru Connector
  • 2 x Male XLR
AC Output Connector
  • powerCON NAC3FCB
Current Draw 230 V / 115 V
  • 1.5 A/3.0 A
Enclosure
Enclosure Construction
  • Birch Plywood
Enclosure Geometry
  • Rectangular
Rigging
  • M10 Rigging Points
Finish
  • ISO-flex Paint
Color
  • Black
Dimensions ( H x W x D )
  • 720 x 545 x 655 mm
    28,3 x 21,5 x 25,8 in
Net Weight
  • 40,5 kg ( 89,2 lb )
Components
LF Driver
  • 18LX
Shipping
Carton Dimensions ( H x W x D )
  • 820 x 616 x 726 mm
    32,3 x 24,3 x 28,6 in
Shipping Weight
  • 44,0 kg ( 97,0 lb )
