SUB 15-AX PROFESSIONAL ACTIVE 15" SUBWOOFER Features
- 2200 Watt Class-D Amplifier
- 133 dB MAX SPL
- 15” Woofer, bass reflex housing
- Digital Crossover w/ Presets
- Multi-ply hardwood polyurea-coated
- LiveRemote App
- Dual XLR/TRS combo Input + Link, Dual XLR Xover Out
- Bass Motion Control excursion management
- Powercon True1 Top Sealed AC Connector
The SUB 15-AX is a portable 15" high-power active subwoofer for live sound applications with fully featured processing, a color touch panel, and remote control via Bluetooth®. The combination of a latest-generation transducer with a powerful Class-D amplifier delivers sound pressure levels up to 133 dB with exceptional clarity and headroom.
SUB AX subwoofers are designed specifically for small to mid-sized venues and ideal for portable applications. SUB 15-AX is the ideal complement for 10" or 12" woofer-size loudspeakers; it centralizes speaker management inside the subwoofer, providing dual crossovers, 8-band EQs, routing, delays, cardioid configurations, and recallable crossover presets.
The polyurea-coated all-wood cabinet features a sealed Powercon True1 Top connector.
Acoustical specifications
- Frequency Response: 35 Hz ÷ 120 Hz
- Max SPL @ 1m: 133 dB
Transducers
- Woofer: 1 x 15'', 3.0'' v.c
Input/Output section
- Input signal : bal/unbal
- Input connectors : Combo XLR/Jack
- Output connectors : XLR
- Input sensitivity : -2 dBu/+4 dBu
Processor section
- Protections: Thermal
- Limiter : Soft Limiter
- Controls : Encoder for Volume control and data entry. Touch Screen for parameter management and monitor.
Power section
- Total Power : 2200 W Peak, 1100 W RMS
- Cooling : Convection
- Connections : Powercon TRUE1 TOP IN/OUT
Standard compliance
- Safety agency : CE compliant
Physical specifications
- Handles : 1 handle per side
- Pole mount/Cap : Yes
- Color : Black, White
Size
- Height : 590 mm / 23.23 inches
- Width : 420 mm / 16.54 inches
- Depth : 590 mm / 23.23 inches
- Weight : 31.4 kg / 69.23 lbs
Shipping information
- Package Height : 640 mm / 25.2 inches
- Package Width : 650 mm / 25.59 inches
- Package Depth : 480 mm / 18.9 inches
- Package Weight : 36.5 kg / 80.47 lbs
