2x QSC KS212C Active Dual 12" Powered Cardioid Subwoofer 3600W ClassD Amplified

Product Description

QSC KS212C Active Dual 12" Powered Cardioid Subwoofer 3600W Sub ClassD Amplified

The KS212C subwoofer represents the world’s first-in-class single-box powered cardioid subwoofer solution for highly portable entertainment and installation applications.

A breakthrough in innovation and design, the 3,600 Watt KS212C subwoofer uniquely provides all the benefits of cardioid deployment in a single, compact enclosure. “Keeping bass in its place” for mobile entertainers, AV production and rental professionals, as well as modestly-sized performance venues, the KS212C subwoofer is unparalleled in its ability to manage low frequencies on the stage, or any application where undesirable low frequency energy needs to be minimized.

Features

3600 Watt Class D power module
Dual 12-inchlong excursion drivers;Dual 6th order band-pass design
15 dB SPL attenuation front-to-rear
Two M20 threaded sockets (one on top, one on side) accept 35 mm speaker pole
Four low-noise, heavy-duty casters
HxWxD = 24.5” x 15.5” x 33.5” (622 x 394 x 851 mm)
88.5 lbs (40.1 kg)

Powered by a 3,600 Watt Class D amplifier, processed with the latest DSP technology, and featuring dual 12-inch long excursion drivers each arranged in a 6th order bandpass chamber, these components all combine seamlessly to produce a staggering 15 dB more output at the front of the cabinet than at the rear. Highly portable, the cabinet features comfortable, aluminum handles and four, rear-mounted casters. Two M20 sockets accept a 35mm speaker pole in other horizontal or vertical orientation.

Most subwoofers radiate energy around the entire enclosure, leading to undesirable LF build-up on stage and wasted energy around the sides and rear of the system

The KS212C subwoofer keeps "bass in its place" with a single-box cardioid array that produces an amazing 15 dB more output at the front than at the rear

SPECIFICATIONS	KS212C
Configuration	Dual 6th-order bandpass cardioid subwoofer
LF Transducer	2 x 12” (305 mm), cone
Frequency Response (-6 dB)	44 Hz - 104 Hz
Frequency Range (-10 dB)	39 Hz - 118 Hz
Nominal Coverage Angle	180? Cardioid (15dB rear rejection @ 70Hz)
Maximum Rated SPL1	132dB @1m, peak
Amplifier	Class D 2 x 1800W (peak)
Cooling	Low-noise, variable speed fan
Controls	Power Gain Rotary encoder 2 x selection buttons
Indicators	2 x Power LED (front and rear) Input Signal LED Limiter active LED
Connectors	2 x locking XLR/F ¼” combo 2 x XLR/M (Loop-thru Output) 1 x locking IEC power connector
AC Power Input	Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption	1/8th power
Enclosure Details
Enclosure	18mm birch plywood
Color	Black (RAL 9011)
Grille	Internal woofer cover
Dimensions (HWD) inches	24.5" × 15.5" × 33.5"
Dimensions (HWD) mm	622 mm x 394 mm x 851 mm
Net Weight	40.1 kg (88.5 lbs)
Shipping Weight	TBD
Regulatory	CE, WEEE, UL, CHina RoHS, RoHS II, FCC Class B
Optional Accessories	KS212C Cover, KS-LOC Lock-Out Cover SP-16X Extension Pole
