PRV Audio 8FR250 8" Full-Range Loudspeaker 250 Watts
- The 8FR250 8" full-range driver from PRV Audio makes it easy to add midrange and high frequency to any system. The naturally damped paper cone and optimized whizzer cone gives this driver the ability to produce frequency response from 50 to 18,000 Hz without the need for a crossover in the sensitive midrange band. The 8FR250 is a great option for use in car audio systems and simple portable speaker designs.
Highlights
-
Nominal Impedance: 8 Ohms
-
Rated AES Power Handling (RMS): 125 Watts
-
Program Power: 250 Watts
-
Sensitivity (1W/1m): 93.5 dB
-
Voice Coil Diameter: 1.5″
GENERAL SPECIFICATIONS
-
Nominal Diameter 8″ (203 mm)
-
Nominal impedance 8 Ohms
-
Rated AES Power Handling (RMS)125 Watts
-
Program Power 250 Watts
-
Sensitivity 2.00V at 1m 93.5 dB
-
Recommended Hi Pass Crossover
** **For Full Power Handling75 Hz** **12db Per Octave Crossover
-
Frequency Response at -10dB50 – 18,000 Hz
-
Voice Coil Diameter 1.5″ (38 mm)
-
Voice Coil Wire CCAW
-
Voice Coil Winding Depth 10.0 mm
-
Former Material Kapton
-
Magnetic Gap Depth 6.0 mm
-
Frame Material Stamped Steel
