Features
- 40 W continuous program power capacity
- 1" horn throat diameter
- 25 mm (1 in) aluminium voice coil
- Polyester diaphragm
- 1500 - 18000 Hz response
- 107 dB sensitivity
Specifications
- Throat Diameter: 25 mm (1.0 in)
- Nominal Impedance: 8 Ω
- Minimum Impedance 6.3 Ω
- Nominal Power Handling2: 20 W
- Continuous power handling3: 40 W
- Voice Coil Diameter: 107.0 dB
- Frequency Range: 1.5 - 18.0 kHz
- Recommended Crossover5: 2.5 kHz
- Voice Coil Diameter: 25 mm (1.0 in)
- Winding Material: Aluminium
- Inductance: 0.1 mH
- Diaphragm Material: Mylar
- Flux Density: 1.55 T
- Magnet Material: Ferrite
Mounting and Shipping Info
- Two M5 holes 180° on 76 mm (3 in) diameter
- Overall Diameter: 90 mm (3.5 in)
- Depth: 53 mm (2.1 in)
- Net Weight: 0.8 kg (1.8 lb)
- Shipping Weight" 0.83 kg (1.82 lb)
- Shipping Box: 105x105x65 mm (4.13x4.13x2.56 in)
1x Driver mounted on B&C ME 10 horn.
22 hour test made with continuous pink noise signal within the range from the recommended crossover frequency to 20 kHz. Power calculated on rated minimum impedance.
3 Power on Continuous Program is defined as 3 dB greater than the Nominal rating.
4 Applied RMS Voltage is set to 2.83 V for 8 ohms Nominal Impedance.
5 12 dB/oct. or higher slope high-pass filter.
